PRODUCT
USTRIP
USTRIP
Window Signage
USTRIP은 통풍구조의 초경량 디스플레이 제품 으로 Store Sign, Window Sign,
Street Sign, Building scene lighting등 다양한 분야에서 적용되는 획기적인 광고매체 입니다.
Specifications
| SPECIFICATIONS | Ustrip16 | Ustrip25 | Ustrip31.25 | Ustrip50 |
| Pitch(mm) | 16 | 25 | 31.25 | 50 |
| Pixel Configuration | 1R1G1B | 1R1G1B | 2R2G2B | 4R3G3B |
| Brightness(cd/㎡) | 7000 | 7000 | 7000 | 5000 |
| LED Type | DIP346 | |||
| Optimum Viewing Angle | H:110° V:60° | |||
| Physical Density(dot/㎡) | 3600 | 1600 | 1024 | 400 |
| Strip Module Size(mm) | 10x1500x22 | 10x1500x22 | 16x1500x24 | 24x2000x24 |
| Cabinet Size(mm) | 500 x 1500 | 500 x 1500 | 500 x 1500 | 800 x 2000 |
| Cabinet Weight(kg/sqm) | 16 | 12 | 15 | 49 |
| Power Consumption(Max/Ave)(W/panel) | 480 / 150 | 280 / 85 | 260 / 80 | 396 / 132 |
| Transparency | 40% | 60% | 48% | 50% |
| Driving Method | Static | |||
| Material | Aluminum | |||
| IP Rating | IP65 | |||
| OperatingTemperature/Humidity(℃/RH) | -20C~50℃/10%~90% | |||
USTRIP Detail
Key Feature
Ultra light
63% Lighter than traditional LED display.
Save Maintenance Cost
High waterproof/robust support frame/all weather operation
Save Labor Cost
Easy installation.
Ensure Security
All Weather Opreating(Rain/Thunder streak/Sand storm/Snow)
Save Power
1/3 Average power consumpthin of the traditional.
Adapt to your project
Curving Installation/Strong Adaptation/Customized Size
[시공 사례]
